Quality control of marketed herbal products of Asparagus racemosus  Willd. through high performance thin layer chromatography (HPTLC) analysis

Bibhuti Bhusan Champati; Bhuban Mohan Padhiari; Asit Ray; Sudipta Jena; Ambika Sahoo; Tirthabrata  Sahoo; Pratap Chandra Panda; Sanghamitra Nayak

doi:10.14719/pst.2206

Authors

Bibhuti Bhusan Champati Center for Biotechnology, Siksha ‘O’ Anusandhan (Deemed to be) University, Kalinga Nagar, Bhubaneswar, Odisha-751 003, India https://orcid.org/0000-0003-2792-0280
Bhuban Mohan Padhiari Center for Biotechnology, Siksha ‘O’ Anusandhan (Deemed to be) University, Kalinga Nagar, Bhubaneswar, Odisha-751 003, India https://orcid.org/0000-0002-2371-639X
Asit Ray Center for Biotechnology, Siksha ‘O’ Anusandhan (Deemed to be) University, Kalinga Nagar, Bhubaneswar, Odisha-751 003, India https://orcid.org/0000-0002-6111-9529
Sudipta Jena Center for Biotechnology, Siksha ‘O’ Anusandhan (Deemed to be) University, Kalinga Nagar, Bhubaneswar, Odisha-751 003, India https://orcid.org/0000-0003-4770-6185
Ambika Sahoo Center for Biotechnology, Siksha ‘O’ Anusandhan (Deemed to be) University, Kalinga Nagar, Bhubaneswar, Odisha-751 003, India https://orcid.org/0000-0002-5016-3735
Tirthabrata Sahoo Department of Botany, Science College, Konkarada, Ganjam, Odisha-761 144, India https://orcid.org/0000-0001-6984-8999
Pratap Chandra Panda Center for Biotechnology, Siksha ‘O’ Anusandhan (Deemed to be) University, Kalinga Nagar, Bhubaneswar, Odisha-751 003, India https://orcid.org/0000-0001-6984-8999
Sanghamitra Nayak Center for Biotechnology, Siksha ‘O’ Anusandhan (Deemed to be) University, Kalinga Nagar, Bhubaneswar, Odisha-751 003, India https://orcid.org/0000-0001-9038-261X

DOI:

https://doi.org/10.14719/pst.2206

Keywords:

Asparagus racemosus, Shatavarin IV, HPTLC, Quality control, Adulteration, Herbal products.

Abstract

Asparagus racemosus Willd. is a valuable medicinal plant which is used all over the world. There are several marketed products of A. racemosus. The high demand for this herb has increased the risk of adulteration in its commercial products. The adulterated herbal products might pose serious ill effects on health. Therefore, it is necessary to check the quality of marketed products in terms of the presence of their major bioactive compounds. The present study aimed to carry out the qualitative and quantitative analysis of Shatavarin IV in marketed products of A. racemosus through a validated high performance thin layer chromatography (HPTLC) method. Ten marketed products were analysed and all of them had shown the presence of Shatavarin IV which was quantified. The identification and quantification were done by taking a standard Shatavarin IV as reference. The Shatavarin IV was detected at Rf 0.4±0.05 and showed maximum absorption at 425 nm. The Shatavarin IV was quantified using a 6-point calibration curve having a standard deviation of 3.89 % with an R2 value of 0.9968. The amount of Shatavarin IV varied between 1.47±0.25 to 2.69±0.51 mg/g on a dry weight basis which is a normal range in the raw plant materials. Thus, the present findings would be a simple, reliable and cost-effective method for the quality determination of herbal products of A. racemosus. The developed HPTLC chromatograms would serve as a reference for the quality assessment of commercial products of A. racemosus in future.

Downloads

Download data is not yet available.

References

Sharma M, Sharma A, Kumar A. Vital medicine Asparagus racemosus Willd. Curr Trends Biotechnol Pharm. 2012;6.

Shaha P, Bellankimath A. Pharmacological profile of Asparagus racemosus: A review. Int J Curr Microbiol Appl. Sci. 2017; 6:1215-23. https://doi.org/10.20546/ijcmas.2017.611.144

Bopana N, Saxena S. Asparagus racemosus-Ethnopharmacological evaluation and conservation needs. J Ethnopharmacol. 2007;110:1-5.

https://doi.org/10.1016/j.jep.2007.01.001

Maraseni TN, Maroulis J, Cockfield G. An estimation of willingness to pay for Asparagus (Asparagus racemosus Willd.) collectors in Makawanpur District, Nepal. J For Sci 2008; 54:131-37. https://doi.org/10.17221/3099-JFS

Ichim MC. The DNA-based authentication of commercial herbal products reveals their globally widespread adulteration. Front Pharmacol. 2019; 10:1227. https://doi.org/10.3389/fphar.2019.01227

Ba?aran N, Pasl? D, Ba?aran AA. Unpredictable adverse effects of herbal products. Food Chem Toxicol. 2022; 159:112762. https://doi.org/10.1016/j.fct.2021.112762

Tistaert C, Dejaegher B, Vander Heyden Y. Chromatographic separation techniques and data handling methods for herbal fingerprints: a review. Analytica Chimica Acta. 2011; 690:148-61. https://doi.org/10.1016/j.aca.2011.02.023

Ram M, Abdin MZ, Khan MA, Jha P. HPTLC fingerprint analysis: a quality control for authentication of herbal phytochemicals. “high-performance thin-layer chromatography (HPTLC)” 2011. p. 105-16. Springer, Berlin, Heidelberg. https://doi.org/10.1007/978-3-642-14025-9_7

Haldar S, Mohapatra S, Singh R, Katiyar CK. Quantitative evaluation of shatavarin IV by high-performance thin-layer chromatography and its isolation from Asparagus racemosus Willd. JPC-Journal of Planar Chromatography-Modern TLC. 2018; 31:197-201. https://doi.org/10.1556/1006.2018.31.3.3

International Conference on Harmonization (2005) ICH Q2 (R1): Validation of Analytical Procedures: Text and Methodology, ICH Secretariat, Geneva.

Patil D, Gautam M, Gairola S, Jadhav S, Patwardhan B. Effect of botanical immunomodulators on human CYP3A4 inhibition: Implications for concurrent use as adjuvants in cancer therapy. Integr Cancer Ther. 2014; 13:167-75. https://doi.org/10.1177/1534735413503551

Patil D, Gautam M, Gairola S, Jadhav S, Patwardhan B. HPLC/Tandem mass spectrometric studies on steroidal saponins: An example of quantitative determination of shatavarin IV from dietary supplements containing Asparagus racemosus. Journal of AOAC international. 2014; 97:1497-502. https://doi.org/10.5740/jaoacint.13-382

Shalini K, Ilango K. Macroscopical and microscopical analysis of selected Indian medicinal plants and HPTLC method for quantification of chemical markers in a polyherbal formulation. J Pharm Pharmacogn Res. 2022;10:253-69. https://doi.org/10.56499/jppres21.1179_10.2.253

Bhurat MR, Sanghavi RS, Nagdev SA, Patil DP. HPTLC fingerprinting and quantification of Shatavarin IV in extract and polyherbal formulations. World J Pharm Res. 2018; 7:442-51.

Nicoletti M. HPTLC fingerprint: a modern approach for the analytical determination of botanicals. Revista Brasileira de Farmacognosia. 2011; 21:818-23. https://doi.org/10.1590/S0102-695X2011005000131

Guzelmeric E, Ristivojevi? P, Vovk I, Milojkovi?-Opsenica D, Yesilada E. Quality assessment of marketed chamomile tea products by a validated HPTLC method combined with multivariate analysis. Pharm Biomed Anal. 2017; 132:35-45. https://doi.org/10.1016/j.jpba.2016.09.030

Gallo FR, Multari G, Palazzino G, Pagliuca G, Zadeh S, Biapa PC, Nicoletti M. Henna through the centuries: a quick HPTLC analysis proposal to check henna identity. Revista Brasileira de Farmacognosia. 2014; 24:133-40. https://doi.org/10.1016/j.bjp.2014.03.008

Raclariu AC, ?ebrencu CE, Ichim MC, Ciuperc? OT, Brysting AK, de Boer H. What’s in the box? Authentication of Echinacea herbal products using DNA metabarcoding and HPTLC. Phytomedicine. 2018; 44:32-38. https://doi.org/10.1016/j.phymed.2018.03.058

Onlom C, Nuengchamnong N, Phrompittayarat W, Putalun W, Waranuch N, Ingkaninan K. Quantification of saponins in Asparagus racemosus by HPLC-Q-TOF-MS/MS. Nat Prod Commun. 2017; 12. https://doi.org/10.1177/1934578X1701200103

Deshmukh BD, Namdeo AG, Singh S, Fulzele DP, Mahadik KR. Effect of gamma-irradiation processing on microbial decontamination, bioactive shatavarin IV constituent and shelf life of shatavari (Asparagus racemosus) marketed formulations. Radiat Phys Chem. 2020; 174:108896. https://doi.org/10.1016/j.radphyschem.2020.108896

Attimarad M, Ahmed KM, Aldhubaib BE, Harsha S. High-performance thin layer chromatography: A powerful analytical technique in pharmaceutical drug discovery. Pharm Methods. 2011; 2:71-75. https://doi.org/10.4103/2229-4708.84436

Bairy PS. A comparison study of HPLC and HPTLC: principles, instrumentations and applications. ASIO J of Anal Chem (ASIO-JAC). 2015; 1:20-28.

Haghi G, Hatami A, Mehran M. Determination of Shatavarin IV in root extracts of Asparagus racemosus by HPLC-UV. Anal Chem Letters. 2012; 2:1-6. https://doi.org/10.1080/22297928.2012.10648246
